ONA-Press
Machine Description: Hydraulic single action press, tryout press
Machine type: EDB-120-4-R
Manufacturing no. P-00975
Manufactured: 1987
Weight of press: 280 tons
Press force: 1200 tons
Stroke: 1800 mm
Max. opening slide/table: 2200 mm
Min. opening slide/table: 400 mm
Max. tool size: 4200 x 3000 mm
Table type: Moving bolster
Table max. load: 40 tons
Slide working surface area: 4000 x 2500 mm
Table working surface area: 4100 x 3000 mm
Pressure cushions in table: 2 x 200 tons
Pressure cushions in slide: 60 tons
Cut force absorbers: 4
FARO Edge Scan Arm HD
Machine Description: Portable edge and scan arm
Measuring software: Polyworks
Measuring rang: Ø2 700 mm
Weight: 11 kg
Scan rate: 560 000 points/sec
Points/line: 2 000 points/line
Laser: Class 2M
Machine accuracy: +/- 25 µm
Repeatability: 0,029 mm
Operating temp. range: 10ْC – 40ْC
Blohm Planomat 612
Machine Description: Precision Surface & Profile Grinding Machine
Grinding length: 1 200 mm
Grinding width: 600 mm
Table size: 1 200 x 600 mm
Max table load: 800 kg
Machine weight: 5 400 kg
Table speed: 1 to 40 m/min
Max wheel speed: 3 010 rpm
Grinding motor: 24,5 KW Siemens Motor
Grinding wheel: Diameter 406 mm x width 100 mm
Control: Siemens CNC
Options:
• Automatic dressing with compensation
• Automatic dynamic balancing of grinding wheel
• Automatic adjustment of spindle speed
• 1 400 l coolant tank with magnetic drom and paper filter
Blohm Planomat 612
Machine Description: Precision Surface & Profile Grinding Machine
Grinding length: 1 200 mm
Grinding width: 600 mm
Table size: 1 200 x 600 mm
Max table load: 800 kg
Machine weight: 5 400 kg
Table speed: 1 to 40 m/min
Max wheel speed: 3 010 rpm
Grinding motor: 24,5 KW Siemens Motor
Grinding wheel: Diameter 406 mm x width 100 mm
Control: Siemens CNC
Options:
• Automatic dressing with compensation
• Automatic dynamic balancing of grinding wheel
• Automatic adjustment of spindle speed
• 1 400 l coolant tank with magnetic drom and paper filter
FANUC ROBOCUT α - C600iB
Machine Description: High speed and high precision AI wire-cut electric
discharge machine
Cutting stroke: X = 600 mm
Y = 400 mm
Z = 310 mm
Max workpiece thickness: 300 mm
Max workpiece dimensions: 1050 x 775 x 300 mm
Max workpiece mass: 1 000 kg
Max taper angle: 45 degree / 70 mm
High speed: 330 mm² / min
High precision: Roundness 1,2 µm for 30 mm hole cutting
Surface roughness: Ra 0,22 µm
Nano interpolation: 0,001 µm
Control system: FANUC 31i – WB
Options:
• Automatic wire feeding mechanism AWF
• Wide open top cover
• Motorized Z-axis
FANUC ROBOCUT α - C600iB
Machine Description: High speed and high precision AI wire-cut electric
discharge machine
Cutting stroke: X = 600 mm
Y = 400 mm
Z = 310 mm
Max workpiece thickness: 300 mm
Max workpiece dimensions: 1050 x 775 x 300 mm
Max workpiece mass: 1 000 kg
Max taper angle: 45 degree / 70 mm
High speed: 330 mm² / min
High precision: Roundness 1,2 µm for 30 mm hole cutting
Surface roughness: Ra 0,22 µm
Nano interpolation: 0,001 µm
Control system: FANUC 31i – WB
Options:
• Automatic wire feeding mechanism AWF
• Wide open top cover
• Motorized Z-axis
FANUC ROBOCUT α - C800iB
Machine Description: High speed and high precision AI wire-cut electric
discharge machine
Cutting stroke: X = 800 mm
Y = 600 mm
Z = 310 mm
Max workpiece thickness: 300 mm
Max workpiece dimensions: 1250 x 975 x 300 mm
Max workpiece mass: 3 000 kg
Max taper angle: 45 degree / 40 mm
High speed: 330 mm² / min
High precision: Roundness 1,2 µm for 30 mm hole cutting
Surface roughness: Ra 0,22 µm
Nano interpolation: 0,001 µm
Control system: FANUC 31i – WB
Options:
• Automatic wire feeding mechanism AWF
• Wide open top cover
• Motorized Z-axis
FANUC ROBOCUT α - C800iB
Machine Description: High speed and high precision AI wire-cut electric
discharge machine
Cutting stroke: X = 800 mm
Y = 600 mm
Z = 310 mm
Max workpiece thickness: 300 mm
Max workpiece dimensions: 1250 x 975 x 300 mm
Max workpiece mass: 3 000 kg
Max taper angle: 45 degree / 40 mm
High speed: 330 mm² / min
High precision: Roundness 1,2 µm for 30 mm hole cutting
Surface roughness: Ra 0,22 µm
Nano interpolation: 0,001 µm
Control system: FANUC 31i – WB
Options:
• Automatic wire feeding mechanism AWF
• Wide open top cover
• Motorized Z-axis
DECKEL MAHO DMU 600 P
Machine Description: 5 axis Portal machine for large part manufacturing
Traverse rang: X = 6 000 mm
Y = 4 200 mm
Z = 3 250 mm
Rapid traverse: Max 30m/min
Spindle taper: HSK63, HSK100
Spindle revs: 28 000 / 12 000 / 6 000 rpm
Spindle drive: Vertical (6 000 rpm) – 50 kW
HSK 100 (12 000 rpm) – 42 kW
HSK 63 (28 000 rpm) – 27 kW
Spindle torque: Vertical (6 000 rpm) – 1 443 Nm
HSK 100 (12 000 rpm) – 300 Nm
HSK 63 (28 000 rpm) – 38 Nm
Coolant through spindle: 80 bar 40 l / min
Air through spindle: 6 bar 660 l / min
Table: 5 000 x 2 800 mm
Max table load: 40 000 kg
Control: 3D contouring control iTNC 530
Tool magazine: HSK100 – 160 Pockets
HSK63 – 20 Pockets
Part measuring: Infrared measuring probe Heidenhain TS 640
Tool measuring: Blum Laser NT-Hybrid
DECKEL MAHO DMC 100 U duoBLOCK
Machine Description: 5 axes universal machining centre with duoblock construction and pallet changer
Traverse rang: X = 1000 mm
Y = 1000 mm
Z = 1000 mm
B = 90 degree
C = 360 degree
Spindle taper: HSK-100 A
Spindle revs: 12000 rpm
Spindle drive: 44 kW 40 % DC
32 kW 100 % DC
Spindle torque: 288 Nm 40 % DC
187 Nm 100 % DC
Coolant through spindle: 40 bar 23 l / min
80 bar 15 l / min
Selected with NC program
Air through spindle: 6 bar 660 l / min
Table: 2 pallets 1000 mm x 800 mm
Max table load: 2 000 kg
Control: 3D contouring control iTNC 530
Tool magazine: 120 pockets
Chip to chip time: 7,5 s VDI 2852
Part measuring: Infrared measuring probe Heidenhain TS 640
Tool measuring: Blum Laser NT-Hybrid
Machine accuracy: P = 0,008 mm VDI / DGQ 3441 X- Y- Z-axis
DECKEL MAHO DMU 75 monoblock
Machine Description: 5 axis simultaneous machining with monoblock construction
Traverse rang: X = 750 mm
Y = 650 mm
Z = 560 mm
Spindle taper: HSK-A63
Spindle revs: 20 000 rpm
Spindle drive: 35kW 40% DC
Spindle torque: 140 Nm 40% DC
Coolant through spindle: 40 bar 23 l / min
Air through spindle: 6 bar 660 l / min
Table: Ø650 / 800 x 650
Max table load: 600 kg
Control: 3D contouring control iTNC 530
Tool magazine: 60 pockets
Chip to chip time: 4,9 sec
Part measuring: Infrared measuring probe Heidenhain TS 640
Tool measuring: Blum Laser NT-Hybrid
Machine accuracy: P = 0,008 mm VDI / DGQ 3441 X- Y- Z-axis
DECKEL MAHO DMU 75 monoblock
Machine Description: 5 axis simultaneous machining with monoblock construction
Traverse rang: X = 750 mm
Y = 650 mm
Z = 560 mm
Spindle taper: HSK-A63
Spindle revs: 20 000 rpm
Spindle drive: 35kW 40% DC
Spindle torque: 140 Nm 40% DC
Coolant through spindle: 40 bar 23 l / min
Air through spindle: 6 bar 660 l / min
Table: Ø650 / 800 x 650
Max table load: 600 kg
Control: 3D contouring control iTNC 530
Tool magazine: 60 pockets
Chip to chip time: 4,9 sec
Part measuring: Infrared measuring probe Heidenhain TS 640
Tool measuring: Blum Laser NT-Hybrid
Machine accuracy: P = 0,008 mm VDI / DGQ 3441 X- Y- Z-axis
DECKEL MAHO DMF 360
Machine Description: 3 axes travelling column milling machine
Machine type: DMF 360
Serial number: 15195362764
Manufactured: 2011
Traverse rang: X = 3600 mm
Y = 1100 mm
Z = 900 mm
Spindle taper: HSK-100 A
Spindle revs: 10000 rpm
Spindle drive: 44 kW 40 % DC
32 kW 100 % DC
Spindle torque: 288 Nm 40 % DC
187 Nm 100 % DC
Coolant through spindle: 40 bar 23 l / min, Selected with NC program
Air through spindle: 6 bar 660 l / min
Table: 4200 x 1100 mm
Table max. load: 5000 kg
Control: 3D contouring control iTNC 530
Tool magazine: 120 pockets
Chip to chip time: 9,0 s VDI 2852
Part measuring: Infrared measuring probe Heidenhain TS 64
Tool measuring: Heidenhain TT 14
Machine accuracy: P = 0,001 mm VDI / DGQ 3441 X- Y- Z-axis
